Ritar 10KWH -51.2V200AH

IEC62619, UN38.3,ROHS, UL1973 & UL9540A Cell Certification Dimensions [W*D*H,mm] : 520x165x865 Product Weight [Kg] 0 SOC, RUN, ALARM display and PC software for detailed operation RS485, CAN communication port for inverter Battery certification: UN38.3, MSDS, CE Independent protection for charge and discharge Series Support: No Support Protection: Over voltage, Low voltage, Over current, Over Temperature, Low Temperature, Short Circuit ELECTRICAL DATA | Model BAT-10KWH-51.2V 200A Nominal Voltage [V] 51.2 Nominal Capacity [Ah] 200 Total Energy [KWh] 10.24 Charging Current [A] 200 Charging Voltage [V] 2~57.6 Discharging Current [A] 200 Pulse Discharge Current: 220A@60s / 240A@10s End of Discharge Voltage [V] 8 (Backup Application) / 48 (Cycle Application) Operating humidity 0-95% RH (No condensing) Operating Temperature range Charge: 0~+55’C, Discharge : -20~+55’ C Cycle Life >6000 Parallel Support: YES, Max 6 Sets Optional Part: Bluetooth Module, 400W Heater parts, Distribution box (for parallel connection)
