• Ultra-reliable Lithium Iron Phosphate Technology. • High Performance: o Power output = 5.2kW (continuous) o Fully rechargeable in 2 hours. • Robust & Durable: o Can be discharged to 100% DoD. o Performance cycle life > 8000 cycles. • Safe & Secure: o Over-charge, over-discharge & short-circuit protection. o Non-combustible & 100% Recyclable. • 10 Year warranty Battery Chemistry Lithium Iron Phosphate (LiFePO4) Nominal Voltage 51.2V Ah Rating 100Ah @C3, 25°C Installed Capacity @Vnom 5 120Wh Cycle life @100% DoD, C1 3000 cycles (5 200Wh) Cycle life @100% DoD, C2 5000 cycles (5 200Wh) Cycle life @80% DoD, C2 7500 cycles (4 160Wh) Internal Resistance ? 30m? @1kHz AC Operating Voltage Range 46.0V ~ 55.0V Bulk Voltage (max.) 55.0V ± 0.3V Float Voltage (recommended) 54.0V ± 0.3V Low-Voltage (min.) 46.5V Charge Current (max.) 60A continuous | ? 60A recommended Discharge Current (max.) 100A continuous Self-discharge Rate Residual capacity: ? 3% /month | ? 15% /year Recover capacity: ? 1.5% /month | ? 8% /year Operating Temperature Range @Charge: 0°C ~ +45°C @Discharge: –20°C ~ +60°C Recommended Operating Environment Temp. range: +15 ~ +35°C | Humidity: 45 ~ 75%RH Storage Environment (stored ? 1 month) Temp. range: –20 ~ +35°C | Humidity: 45 ~ 75%RH Storage Environment (stored ? 3 months) Temp. range: +10 ~ +45°C | Humidity: 5 ~ 75%RH Dimensions – Main enclosure 442mm x 520mm x 178mm (L x W x H) Dimensions – Front plate 483mm x 178mm (L x H) Net Weight 55.0kg (unboxed, no accessories) Serial Communication CAN and RS485
