Features & Benefits:

• Outstanding cutting performance in both small profiles and large construction timbers up to 110 x 303 mm
• XPS Shadow line cut indicator provides fast accurate alignment of the blade while illuminating the work piece for increased productivity no adjustment required
• Heavy duty durability with the ability to fully adjust your machine to maintain accuracy over the life of the tool
• New quick release bevel stop setting provides accurate and simple setting of bevel angles up to 49 degrees left and right
• Easy to use mitre and bevel controls making the tool fast and simple to change from one set up to another
• Cam action mitre lock function makes mitre setting faster and easier allowing the user to quickly adjust angles between 0 degrees - 50 degrees left and 0 degrees - 60 degrees right
• Long life accuracy in table and fence design
• The large dual sliding fence gives maximum support in large material cuts at any angle or combination of angles
• Linear horizontal rails utilise bronze guides to provide maximum precision when cutting materials up to 345 mm wide
• Compact and lightweight design characteristics deliver a saw with enormous capacity which is easy to transport around the jobsite
• Outstanding dust control and deflection away from cutting area
• Electronic speed control for adjusting cutting speed when cutting materials other than wood
• The innovative grooving stop allows the adjustment of the cutting depth for grooving and rebating applications

Product Specification:

• Power Input: 1675 Watts
• Power Output: 960 Watts
• Blade Speed: 1900 - 3800 rpm
• Blade Diameter: 305 mm
• Blade Bore: 30 mm
• Bevel Capacity: 49/49 degrees
• Mitre Capacity [right/left]: 60/50 degrees
• Cutting Capacity at 90 degrees/45 degrees (W x H): 211 x 112 mm
• Cutting Capacity at 90 degrees/90 degrees (W x H): 303 x 110 mm
• Cutting Capacity at 90 degrees/90 degrees (W x H): 345 x 76 mm
• Cutting Capacity at 45 degrees/90 degrees (W x H): 268 x 63 mm
• Cutting Capacity at 45 degre
