High Voltage VDC500V 6.2KVA/6200W 100A Pure Sine Wave Solar Inverter Features - Pure Sine Wave Solar Inverter - Output Power Factor 1 - High PV Input Voltage Range (120VDC - 500VDC) - Built-in 120A MPPT Solar Controller - Supports Multiple Output Priority: UTL, SOL, SBU, SUB - Non Paralell - RS485 Communication for BMS - Battery Equalization Function to Optimise Battery Performance and Extended Lifecycle Specifications:- Inverter Mode - Rated Power: 6200VA / 6200W - DC Input: 48VDC, 127A - AC Output: 230VAC, 50/60Hz, 23.9A AC Charger Mode - AC Input: 230VAC, 50/60Hz, 40A - DC Output: 54VDC - Max. Charge Current(AC): 60A Default 30A - Max. Charge Current(PV+AC): 100A - AC Output: 230VAC, 50/60Hz, 23.9A Solar Charge Mode - Max. PV Array Power: 6200W - Min. Solar Voltage: 120VDC - Max. Solar Voltage (VOC): 500VDC - Max. MPPT Charge Current: 120A Ingress Protection: IP21 (Indoor Use) Dimensions ; 38 x 55 x 20 cm Weight : 9.65kg Battery Specs LFEI-51.2V 100AH Rated Capacity 100ah With Display Screen Intra system Balancing Flame retardent Automatic Over Charge Protection 20 year Design Life IP31 Class 19" std cabinet or can be wall mounted It is recomended to use ECCO Batteries and Solar Panels for Quality Garanteed Results. Important Note: This product requires installation by a qualified PV installer, the PV installer must be able to issue a Certificate of Compliance. This is to ensure that the installation is safe and correct, as well as, within the scope of relevant regulations. Solar Panel Specs 580W Maximum Power Mono Solar Cell Anodized Aluminum Alloy 46.53V Operating Voltage 21.1 Module Efficiency 13.89 Amp Operating Current 49.95 Operating circuit voltage -40C - +85C Operating Temperature What's in the box 1 x ECCO 6.2KW Inverter 3 x Connecting Cables 2 x User Guide 1 x 51v/100ah Lithium Ion Battery 6 x Ecco 580w Solar Panel 1 x Stier Socket Set
