Features PV Input Max. PV Input Power: 7500 Wp Max. PV Input Voltage: 600 V Nominal Input Voltage: 360 V MPPT Voltage Range: 125-550 V No. of MPPTs/Strings per MPPT: 2/1 Max. PV Current: 14 A Max. Short Circuit Current: 17/17.5 A AC Output @ Grid Nominal AC Power: 5000 W Max. Apparent Output Power: 5000 VA Nominal AC Voltage: 220 V/230 V/240 V Nominal AC Voltage Range: 186-290 V AC Frequency: 50 Hz/60 Hz Max. AC Current: 23.9 A THDi, Rated Power: <3% Power Factor: ~1 (Adjustable from 0.8 Leading to 0.8 Lagging) EPS Output @ Off Grid Nominal EPS Power: 5000 W EPS Peak Power: 1.1 x Pnom (60 sec); 1.5 x Pnom (1 sec) Nominal Output Voltage: 220 V/230 V Nominal Frequency: 50 Hz/60 Hz Nominal Output Current: 21.7 A THDv, Rated Power: <3% Battery Input Battery Type: Lithium Battery Voltage: 40-60 V Max. Charge/Discharge Current: 100 A Communication with BMS: CAN Efficiency Max. Efficiency: 97.8% Euro Efficiency: 97.4% General Data Dimensions (WDH): 415625155 mm Weight: 30 kg Mounting Method: Wall Mount Bracket Protection Rating: IP65 Cooling: Natural Convection Operating Temperature Range: -25°C to +60°C (Derating >45°C) Display: LED & APP Communication: Wi-Fi/DRM/CAN/RS485 Standard Warranty: 2 Years
