SUNPOLO - 6KW/48V Hybrid Solar Inverter - 120A MPPT + Parallel Function - WIFI Optional
Main image
Click to view image in fullscreen
calcActive())" class="flex gap-3 lg:gap-4 justify-center h-10 lg:h-[64px]">
Product Images
Main image
Click to view image in fullscreen
calcActive())" class="flex gap-3 lg:gap-4 justify-center lg:h-full lg:justify-start h-[64px] mt-6">
SKU
e44aa3e2
Online Product | Delivery Only
Unavailable in Store
Product Information
120A MPPT solar charger inside, max pv input 6kw+ (27A) - With local wifi built inside (Requires App. Remote Wifi optional) - USB on-the-go function - Optional for parallel operation of up to 9 units - User-programmable RGB lighting for different operation modes - BMS built-in, w...
More Information
Show more information
R 18,999.00
R 21,995.00
Easy Return & Refunds
Nationwide Delivery
Free Click & Collect
Pargo Pickup
Standard Delivery Fees Apply
Qualifies for
Free Delivery
For Orders Over
R2500.00
120A MPPT solar charger inside, max pv input 6kw+ (27A) - With local wifi built inside (Requires App. Remote Wifi optional) - USB on-the-go function - Optional for parallel operation of up to 9 units - User-programmable RGB lighting for different operation modes - BMS built-in, with smart battery management.Compatible with LiFePO4 - On-grid and off-grid solar inverters support self-consumption and feed into the grid - Various communication include USB/RS232/RS485/dry contact/WIFI/ optional - Touch buttons on the LCD - With 12Vdc output (when having batteries) and Dual AC output - Wide PV input range (Up to 500Vdc), support no battery working during the day- Please read returns policy for T&C's
Features:
BASICAL INFORMATION
Max. PV Input Power: 6000W
Rated AC Output Power: 6000W
PV INPUT (DC)
Nominal DC Volt/Max. DC Voltage: 360VDC/500VDC
Start-up Voltage/Initial Feeding Voltage: 120VDC
MPPT Voltage Range: 120-450VDC
No. of MPPT Tracker/Max. Input Current: 1/27A
AC INPUT (AC)
AC Start-up Voltage/Auto Restart Volt.: 120VAC-140VAC/180VAC
Acceptable Input Voltage Range: 90-280VAC/170-280VAC
Max. AC Input Current: 40A
GRID OUTPUT IN GRID-TIE/HYBRID OPERATION (AC)
Nominal Output Volt: 220VAC/ 230VAC/240VAC, Single Phase dual AC output
Output Voltage Range: 184V-265VAC or 195-253V (Selectable)
Nominal Output Current: 26.0A
Power Factor: 1
Max. Conversion Efficiency (DC/AC): 96%
BATTERY MODE OUTPUT (AC)
Nominal Output Volt: 230VAC dual AC output+ 1pc*12VDC/10A max.
Waveform: Pure sine wave
Efficiency (DC to AC): 93%
BATTERY & CHARGER
Battery Type Supported: Lead Acid /VRLA/AGM/Deep Cycle/Gel/Flooded/Tubular/Lithium-Ion
Nominal Battery Voltage: 48VDC
Max. Solar Charge Current: 120A
Max. AC Charge Current: 120A
Max. Total Charge Current: 120A
OPERATING ENVIRONMENT
Humidity: 5% to 95% Relative Humidity (Non-condensing)
Operating Temperature: -10℃-50℃
Storage Temperature: -15℃-60℃
Product label
SUNPOLO - 6KW/48V Hybrid Solar Inverter - 120A MPPT + Parallel Function - WIFI Optional
SKU
e44aa3e2
Pargo Available
No
Ean code
6009234037060
Gross weight (kg)
15.00
Product width in cm
36.00
Product depth in cm
47.00
Product height in cm
15.00
