With the Xiaomi Dual Band AC1200 Router, you can enjoy a wireless dual band speed of 1167Mbps for a faster and smoother online experience. The Xiaomi Router supports Smart join, which combines the 2.4GHz and 5GHz bands into a single Wi-Fi name. This eliminates uncertainty about which Wi-Fi network to join. The 2.4GHz band delivers better performance through walls, while 5GHz provides faster speeds. A dual-band terminal chooses the best frequency band automatically.

4 precision-tested external omnidirectional antennas with a carefully designed internal structure and configuration significantly enhance transmission performance, especially in complicated situations. A carefully prepared metal substrate is coupled with nanomaterials with superior thermal radiation properties. It has high heat absorption and heat dissipation properties, allowing it to effectively lower chip temperature and increase system stability. The Xiaomi Router includes a big 64MB memory, which ensures data transfer stability and connectivity of each access device.

FEATURES:

• 4 External Antennas
• Dual-Core CPU
• Large 64 MB memory for stable connection of 64 devices
• Control remotely via the Mi Home App
• Unauthorized access prevention
• Parental Control

SPECIFICATIONS:

• CPU: MT7628DA
• ROM: 16MB
• RAM: 64MB
• 2.4GHz Wi-Fi: 2x2 (supports the IEEE 802.11n protocol, maximum possible speed of 300Mbps)
• 5GHz Wi-Fi: 2x2 (supports the IEEE 802.11ac protocol, maximum possible speed of 867Mbps)
• Product antennas: 4 external omnidirectional antennas (two 2.4GHz antennas with maximum gain of 5dBi; two 5GHz antennas with maximum gain of 6dBi)
• Product heat dissipation: Natural heat dissipation
• Total interfaces: Two 10/100M self-adaptive LAN ports (Auto MDI/MDIX), One 10/100M self-adaptive WAN port (Auto MDI/MDIX)
• LED indicator lights: 2
• System reset buttons: 1
• Power input interface: 1
• Protocol standards: IEEE 802.11a/b/g/n/ac, IEEE 802.3/3u
• Certification standards: GB9254-2008 YD/T993-1998 GB4943.1-2011
• Dual band: 2.4GHz and 5GHz
• Operating system: Mi Wi-Fi ROM intelligent router operating system based on a highly customized version of OpenWRT
• Wireless security: WPA-PSK/WPA-PSK2 encryption, wireless access control (blacklist and whitelist), SSID hiding, smart unauthorized access prevention
• Management Application: Supports web, Android, and iOS
• Product Dimensions: 19 x 10 x 17.5 cm

WHAT’S IN THE BOX:

• Xiaomi AC1200 Dual Band Router 4A  – White x1
• Power Adapter x1
• User Manual x1
