High Voltage VDC500V 3.5KVA/3500W 100A Pure Sine Wave Solar Inverter Features - Pure Sine Wave Solar Inverter - Output Power Factor 1 - High PV Input Voltage Range (120VDC - 500VDC) - Built-in 100A MPPT Solar Controller - Supports Multiple Output Priority: UTL, SOL, SBU, SUB - Parallel Operation with Up to 12 units (Parallel Version) - Supports Parallel Operation in Single Phase/ 3 Phase (Parallel Version) - Supports Wireless Parallel, Without Extra Sharing Current Cable - RS485 Communication for BMS - Wifi Monitoring - Battery Equalization Function to Optimise Battery Performance and Extended Lifecycle Specifications:- Inverter Mode - Rated Power: 3500VA / 3500W - DC Input: 24VDC, 158A - AC Output: 230VAC, 50/60Hz, 23.5A AC Charger Mode AC Input: 230VAC, 50/60Hz, 23.5A DC Output: 27VDC Max. Charge Current(AC): 60A Default 30A Max. Charge Current(PV+AC): 100A AC Output: 230VAC, 50/60Hz, 15.2A Solar Charge Mode Max. PV Array Power: 4000W Min. Solar Voltage: 120VDC Max. Solar Voltage (VOC): 500VDC Max. MPPT Charge Current: 100A Ingress Protection: IP21 (Indoor Use) Dimensions ; 38 x 55 x 20 cm Weight : 9.65kg Battery Specs Lithium Ion Phosphate Lighter weight and higher power 25.6v voltage 100ah standard charge 29.2+- 0.2v Max Pulse current 120a Ip30 Class 25.5kb weight 20 year long cycle Life Solar Panel Specs 410W Maximum Power Mono Solar Cell Anodized Aluminum Alloy 46.53V Operating Voltage 21.1 Module Efficiency 13.89 Amp Operating Current 49.95 Operating circuit voltage -40C - +85C Operating Temperature What's in the box 1 x ECCO 3.5KW Inverter 1 x Wifi Monitoring Module 3 x Connecting Cables 2 x User Guide 1 x 24v/100ah Lithium Ion Battery 6 x Ecco 410w Solar Panel 2 x Stier Torch
