Mecer 5.6Kw 6Kwmppt 48V High Voltage Inverter - Mecer Axpert 5600Va 5600W (Sol-I-Ax-5M4)

Experience the power of the Mecer Axpert 5600VA/5600W Pure Sine Wave Inverter SOL-I-AX-5M4. This high-performance Inverter is designed to optimize and regulate DC power from your solar array, ensuring efficient charging of your battery bank. With its transformer-less design, it delivers reliable power conversion in a compact size.

Stay in control with the customizable status LED ring featuring vibrant RGB lights, and easily navigate the settings using the touchable button and large 4.3" colored LCD display. The wide DC input range provides flexibility for various solar setups.

Take advantage of the USB On-the-Go function for effortless parameter adjustments, data downloads, and software updates. The inverter also features data logging capabilities, allowing you to track its operation status conveniently.

Stay connected and monitor your system on the go with the built-in Wi-Fi functionality. Simply download the Android or iOS app to access real-time information and ensure your system is performing optimally.

For seamless integration with your battery management system (BMS), a reserved communication port is available. Enjoy the convenience of battery-independent operation, and for higher power demands, the inverter supports parallel operation with up to 9 units.

Specifications:

• Rated power: 5600VA/5600W
• Voltage: 230 VAC

Selectable Voltage Range:

• 170-280 VAC (for personal computers)
• 90-280 VAC (for home appliances)
• Frequency Range: 50Hz/60Hz (auto sensing)

Output:

• AC voltage regulation (battery mode): 230 VAC +/- 5%
• Overload capacity: 5s at ≤150% load; 10s at 110%~150% load; 100ms at ≤200% load
• Peak efficiency: 93%
• Transfer time: 10ms (for personal computers); 20ms (for home appliances)
• Waveform: Pure sine wave
• Dual outputs: Yes

Battery:

• Battery voltage: 48 VDC
• Floating charge voltage: 54 VDC
• Overcharge protection: 66 VDC

Solar Charger & AC Charger:

• Solar charger type: MPPT 6000W
• MPPT range at operating voltage: 120 ~ 430 VDC
• Maximum PV array open circuit voltage: 450 VDC
• Maximum solar charge current: 120A
• Maximum AC charge current: 120A

Operating Environment:

• Humidity: 5% to 95% relative humidity (non-condensing)
• Operating temperature: -10°C to 50°C
• Storage temperature: -15°C to 60°C

Package Includes:

• 1 x Inverter
• 1 x Cable
• 1 x DVD
• 1 x User Manual

Invest in the Mecer Axpert 5600VA/5600W Pure Sine Wave Inverter SOL-I-AX-5M4 today and enjoy efficient and reliable power conversion for your solar energy system.
