TP-Link VIGI C340I | 4MP Outdoor IR Bullet Network Camera
Security Never Shuts Down
Available in 2.8, 4 or 6mm Lens
FEATURES:
- 4MP Super-High Definition - The VIGI C340I camera comes with 4MP — more than enough pixels to pick up some of the more discrete details
- Human & Vehicle Classification - Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications
- Smart Detection - Receive notifications and check feeds when someone crosses a boundary, enters an area you've set, obstructs the camera or removes/abandons objects
- Smart Video Enhancement - VIGI' s professional technologies process videos to greatly improve their quality that is vital to your monitoring, including Smart IR, WDR, 3D DNR and Night Vision
- H.265+ - Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads and reduce monitoring costs without sacrificing image quality
- Waterproof - Reliable IP67 for stable outdoor performance
- PoE/12V DC - Two types of power supply not only give you more convenience but also make your wiring remarkably easy
- 2.8/4/6mm Lens - Whether you need a wide-angle lens to cover enclosed spaces or a higher millimeter lens for longer distances in open spaces, the C340I comes with three different lens types to better suit your security needs
- Flexible Management - Take full control over your security via four management methods: the web UI, NVR UI, VIGI app and VIGI Security Manger
SPECIFICATIONS:
| Image Sensor | 1/3” Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Minimum Illumination | Colour: 0.1 Lux; 0 Lux with IR |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Day / Night / Auto / Schedule-Switch |
| Lens | 2.8mm / 4mm / 6mm |
| Aperture | 2.8mm: F2.2 |
| 4mm: F2.2 | |
| 6mm: F2.0 | |
| Lens Mount | M12 |
| Viewing Angle | 2.8mm: 88.8°/48.9°/106.5° (H/V/D) |
| 4mm: 75.1°/41.5°/88.7° (H/V/D) | |
| 6mm: 47.7°/26.5°/56° (H/V/D) | |
| IR Working Distance | 30m |
| Digital Noise Reduction | 3D DNR |
| WDR | DWDR |
| Weatherproof Rating | IP67 |
| LENS | |
| Type | Fixed Focal Lens |
| Focal Length | 2.8mm / 4mm / 6mm |
| Aperture | 2.8mm: F2.2 |
| 4mm: F2.2 | |
| 6mm: F2.0 | |
| FOV | 2.8mm: |
| Horizontal FOV: 88.8°, Vertical FOV: 48.9°, Diagonal FOV: 106.5° | |
| 4mm: | |
| Horizontal FOV: 75.1°, Vertical FOV: 41.5°, Diagonal FOV: 88.7° | |
| 6mm: | |
| Horizontal FOV: 47.7°, Vertical FOV: 26.5°, Diagonal FOV: 56° | |
| Lens Mount | M12 |
| DORI Distance | 2.8mm: |
| Detect: 60m | |
| Observe: 25m | |
| Recognize: 12m | |
| Identify: 6m | |
| 4mm: | |
| Detect: 80m | |
| Observe: 33m | |
| Recognize: 16m | |
| Identify: 8m | |
| 6mm: | |
| Detect: 120m | |
| Observe: 50m | |
| Recognize: 24m | |
| Identify: 12m | |
| VIDEO | |
| Max. Resolution | 2560 × 1440 |
| Main Stream | Frame Rate: |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |
| Resolution: | |
| 2560 x 1440, 2304 x 1296, 2048 x 1280, 1920 x 1080, 1280 x 720 | |
| Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps | |
| Sub-Stream | Frame Rate: |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |
| Resolution: | |
| 640 x 480, 352 x 288, 320 x 240 | |
| Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps | |
| Bit Rate Control | CBR, VBR |
| Video Compression | Main Stream: H.265+ / H.265 / H.264+ / H.264 |
| Sub-Stream: H.265 / H.264 | |
| H.264 Type | Main Profile / High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265+ | Main Stream Supported |
| Video Bit Rate | Main Stream: 256Kbps to 4Mbps |
| Sub-Stream: 64Kbps to 512Kbps | |
| ILLUMINATOR | |
| IR LED | Quantity: 2 |
| Range: 30m | |
| Wavelength: 850nm | |
| White LED | N/A |
| Illuminator On/Off Control | Auto / Scheduled / Always on / Always off |
| Angle Adjustment (Manual) | |
| Range | Pan: -90° to 90° |
| Tilt: -90° to 90° | |
| Image | |
| Image Settings | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software, Rotation (90°/270°) |
| Image Enhancement | BLC / 3D DNR / HLC / SmartIR |
| Wide Dynamic Range | DWDR |
| SNR | ≥ 52 dB |
| Image Parameters Switch | Yes |
| Privacy Mask | Up to 4 Masks |
| ROI | 1 Region |
| OSD Setting | Yes |
| AUDIO | |
| Audio Communication | N/A |
| Audio Input | N/A |
| Audio Output | N/A |
| Audio Compression | N/A |
| Audio Sampling Rate | N/A |
| Environment Noise Filtering | N/A |
| Audio Bit Rate | N/A |
| NETWORK | |
| Security | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| Network Storage | NAS (NFS, SMB / CIFS) |
| Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| API | ONVIF |
| Simultaneous Live View | 3 Main Streams & 3 Sub-Streams |
| Client | VIGI App, VIGI Security Manager, VIGI NVR, Web |
| Web Browser | Google Chrome 57 and above |
| Firefox 52 and above | |
| Safari 11 and above | |
| Microsoft Edge 91 and above | |
| Cloud | Yes |
| ONVIF | Yes |
| INTERFACES | |
| Network Interface | 1 RJ45 10/100M Self-Adaptive Ethernet Port |
| Alarm | N/A |
| Reset Button | N/A |
| Power | DC Power Port |
| Button | - |
| Video Output | - |
| On-board Storage | N/A |
| Built-in Microphone | N/A |
| Built-in Speaker | N/A |
| Audio | N/A |
| ALARM AND EVENT MANAGEMENT | |
| Smart Event | Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection |
| Basic Event | Motion Detection, Video Tampering Detection, Exception (Illegal Login) |
| Alarm Linkage | Message Push |
| Linkage Method | N/A |
| Output Notification | Message Push |
| GENERAL | |
| Package Contents | VIGI Network Camera |
| Quick Start Guide | |
| Waterproof Cable Attachments | |
| Mounting Accessories | |
| Operating Temperature | -30–60°C |
| Storage Temperature | -40–60°C |
| Storage Humidity | 95% or Less (Non-Condensing) |
| Operating Humidity | 95% or Less (Non-Condensing) |
| Dimensions(H × W × D) | 174 × 74 × 71mm |
| Material | Plastic |
| General Features | Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening |
| Power Requirements | |
| Net Weight | 0.2kg |
| Gross Weight | 0.35kg |
| Power Consumption | 12V DC: Max .5W |
| PoE: Class 0 | |
| Power Supply | 12V DC ± 5%, 5.5mm Coaxial Power Plug |
| PoE (802.3af/at, class 0) | |
| Protection | IP67 |
| Product Dimensions (L x W x H) | 73 × 174 × 71mm |
| Certifications | CE / BSMI / VCCI / ONVIF |
| VIDEO/IMAGE | |
| Video Compression | Main Stream: H.265+ / H.265 / H.264+ / H.264 |
| Sub-Stream: H.265 / H.264 | |
| Frame Rate & Resolutions | Main Stream: |
| Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |
| Resolution: 2560x1440,2304x1296, 2048x1280, 1920x1080, 1280x720 | |
| Sub-Stream: | |
| Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |
| Resolution: 640x480,352x288, 320x240 | |
| Max. Resolution | 4MP (2560 × 1440) |
| Video Streaming | Main Stream |
| Sub-Stream | |
| Image Settings | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software, Rotation (90°/270°) |
| Image Enhancement | BLC / 3D DNR / HLC / SmartIR |
| Video Bit Rate | 64Kbps to 4Mbps |
| Day/Night Switch | Day / Night / Auto / Schedule |
| SMART FEATURE-SET | |
| Smart Event | Human & Vehicle Classification, Intrusion Detection, Line-Crossing Detection, Human Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection |
| Basic Event | Motion Detection, Camera Tampering Detection, Exception (Illegal Login) |
| Linkage Method | Trigger Notification: ONVIF, HTTPS |
| Region of Interest | 1 Region |
