Bluetooth Smart enabled Any Bluetooth enabled smartphone, tablet or other devices can be used to monitor, to change settings
and to update the charger when new software features become available.
Fully programmable

• Battery charge algorithm (configurable) or fixed output.
• Smart alternator compatibility: engine running detection mechanism.

Adaptive 3-stage charge algorithm: bulk – absorption – float

• For lead-acid batteries, it is important that during shallow discharges the absorption time is kept short in order to prevent overcharging of the battery. After a deep discharge, the absorption time is automatically increased to make sure that the battery is completely recharged.
• For lithium batteries, absorption time is fixed default 2 hours.
• Alternatively, a fixed output voltage can be chosen.

Suitable for use in vehicles with a smart alternator (Euro 5 and Euro 6 engines) The built-in engine shutdown detection will stop the converter when the engine is not running.
This prevents the unwanted discharge of the starter battery (see the manual for details).
Remote on-off A remote on/off switch or relay contact can be connected to a two-pole connector.
Alternatively, the H terminal (right) of the two-pole connector can be switched to battery plus, or the L terminal (left) of the two-pole connector can be switched to battery minus (or the chassis of a vehicle, for example).
All models are short circuit proof and can be paralleled to increase output current An unlimited number of units can be connected in parallel.
High temperature protected The output current will reduce at high ambient temperature.
IP43 protection When installed with the screw terminals oriented downwards.
Screw terminals No special tools needed for installation.
Input fuse (not replaceable)
